MENNEKES Panel mounted receptacle 3256

Panel mounted receptacle 3256

Ampere 16 A 32 A
Poles
Voltage
Clock position
  • screw terminals
  • standard flange dimensions
  • 20° inclination
  • receptacles optional fitted with auxiliary contact
  • Part no.3256
  • EAN4015394203056
  • Std. Pack. 10
You can manage our products in various lists in the shopping list / shopping basket area.
Please give the new list a name
  • Please enter a list name
  • The list name already exists
  • Please enter a valid list name

Technical specifications

Panel mounted receptacle 3256

Ampere 32 A
Poles 4 p
Voltage 500 V
Clock position 7 h
Hertz 50-60 Hz
Connection technology Screw terminals
Contact standard
Protection type IP67
Flange 85x85 mm
Fixing hole 70x70 mm
Inclination 20 °
Weight 282 g
Certifications EAC

Datasheets & Downloads

Panel mounted receptacle 3256

Product infoPanel mounted receptacle 3256 PDF, 201 KB
Dimensional drawing portraitPanel mounted receptacle 3256 PNG, 100 KB
Dimensional drawing landscape formatPanel mounted receptacle 3256 PNG, 100 KB

Directives

Panel mounted receptacle 3256

REACh
RoHS
